Vista 3G23 (Low Cost)
The Vista 3G23 is a device that offers much more than just a simple position. Its powerful event engine enables it to provide intelligent reports in high value added logistics and security services that other devices, of the same cost, can’t offer.
Status Indicators:
3 (power supply, GPS and GSM/GPRS)
Dimensions:
75 mm x 53 mm x 22 mm
Weight
65 Grams (no battery)
Power Supply:
8 to 38 VCC
Operating Temperature Range:
-20°C to +70°C (without backup battery)
Humidity:
95% at 60°C
Case:
Injected Nylon
GPS Antenna:
Internal (Optional external antenna active 27 dB)
GSM Antenna:
Internal (Penta-Band)
Overview
Tech Specs
Accessories
Vista 3G23 allows you to comply with all expectations concerning functionality and reliability required by security and logistics applications nowadays. Its small dimensions and low power consumption level, along with powerful hardware, enable you to take advantage of the following characteristics:
Expand All
  • Integrated Intelligence
    Vista 3G23 isn’t configured, it’s programmed. The fundamental difference is that the functions of the device do not depend on something that’s pre-established; instead, through the GAP language, you can execute small logic programs, perform simple mathematical operations, or create your own reports.
  • Connectivity
    Its multiprotocol support gives it the capability to connect through different types of devices such as cellphones, two-way digital radios, or satellite transceivers. When the connection is done through the Internet, its DNS name resolution capability enables an exclusive power to clients who possess registered domains and change IP addresses suddenly.
  • Power Manager
    Enables the proper functioning of the device without discharging the main battery; even when the vehicle’s engine is off.
  • Management and Logistics
    Vista 3G23 offers a full and efficient solution when analyzing, processing, and saving information related to the journey, harsh braking, idling time, engine RPM, vehicle status, and driver information.
  • Access Code
    Ensures that the device configuration and stored information can only be accessed by enabled users.
  • Authenticity of Reports/Messages Sent
    The Vista 3G23 is equipped with the capability of issuing a digital signature to each message sent in order to establish the authenticity of those packets. If this feature is enabled, it eliminates the possibility of receiving incorrect or malicious data within the global network.
  • 3-Axis Motion Sensor
    Detects any alterations in position and/or vibration of the vehicle; whether it’s being towed or has started to shift. If the device is in low power mode (GPS OFF), it can come out of that status and send a report to the base.
  • Storage Capacity
    The Vista 3G23 has the capacity of storing the last 18,000 reports and can process them later.
  • BCM (Battery Charge Management)
    It is of utmost importance for a device that works with batteries to have a proper charge/discharge manager in order to optimize its performance. This manager can be configured according to the needs and/or performance level required; extending battery life.
Technical Specifications
Power Supply
8 to 38 VCC
Internal Backup Battery
Internal model 3.6V 250mA - Lithium-Polymer (optional)
Power Supply Protections
Up to +100 VCC in continuous form
Hasta -400 VCC in continuous form
Consumption
30-40 mA in active mode (24 VCC)
< 8 mA (GPS OFF)
< 0.25 mA in full sleep mode (Kernel ACTIVE)
Operating Temperature Range
-20°C to +70°C (without backup battery)
Humidity
95% at 60°C
Case
Injected Nylon
Dimensions
75 mm x 53 mm x 22 mm
Weight
65 Grams (no battery)
GPS Module
22 (Tracking) / 66 (Acquisition)
< 35 second cold start (average)
Position precision: 10 meters, 2D RMS - 5 meters, 2D RMS, WAAS enabled
Speed precision: 0.1 m/s
Time precision: 1us synchronized with the GPS time
GPS Antenna
Internal – Optional external antenna active 27 dB
Cellular Module
GSM-GPRS-3G
850/1900MHz@UMTS
850/900/1800/1900MHz@GSM
GSM Antenna
Internal (Penta-Band)
Status Indicators
3 (power supply, GPS and GSM/GPRS)
Serial Ports
1 (TTL) (2400 to 115200 bps)
Compatible with ITS USB adaptor
Digital Inputs
5 (protected up to 100 VCC)
1 TTL (not protected)
Analog Inputs
2 (0-40 VCC)(protected up to 100 VCC)
Inputs for RPM Measurement
1 (protected up to 100 VCC)
Outputs
2 - OC NPN (400 mA Max.)(non-volatile state)
1 - 0 to 3.8 VCC
3-Axis Motion Sensor
1 (Adjustable sensibility level)
Configurable Events
196
User-Configurable Reports
16
User-Configurable Triggers/Comparators
32
Analog Windows
8
Abrupt Braking Triggers
4
Change of Course Triggers
8
Time/Distance Triggers
10
Time Control Triggers (date/time)
8
Speed Limit Triggers
8
RPM Limit Triggers
2
Incoming Calls Triggers (Call ID)
8
Time Counters (seconds)
16
General Use Counters-16 bits
32 (0 to 65535) (16 non-volatile)
High-Range General Use Counters
32 (0 to 999999999) (16 non-volatile)
General Use Records for Calculations
32 (16 non-volatile)
Configurable Printout Format
Supported Mathematical Operations:
    = : Assign Value
    + : Addition
    - : Subtraction
    * : Multiplication
    / : Division
    % : Module
    A : Logical Operation AND
    O : Logical Operation OR
    X : Logical Operations XOR
    Q : Square Root
    ^ : Power
Pulse Counters
2 (0 to 4294967295.999) (non-volatile, with 1/1000 resolution and configurable adjustment factor)
General Use Status Flags
32 (16 non-volatile)
System Status Flags
More than 96
Geographic Reference Points (WayPoints)
100
Geographic Zones
32 (resolution of up to 32 points per zone)
GSM Band Country Code Triggers (MCC)
4
Incoming Data Processing
2 totally configurable triggers.
Binary texts or data incoming from any data port can be processed and/or converted
Ex: Serial Port (TR0) / GPS Listener Port /  GSM Modem Listener Port
Odometers
2 Total and Partial (resolution in meters)
Dynamic Assignment of Variables
Configuration of multiple assigned variables to different parameters of the device in the same command
Driver or User Management
Information of:
    - Date and time of session start
    - Length of session
    - Time with idle engine
    - Running time
    - Travelled distance (resolution in meters)
    - Three general use counters
    - Status or mode change
Possibility of loading a list of up to 64 enabled codes
GPRS Connection Capability
2 configurable IP destinations
SMS Connection Capability
2 configurable destinations
Storage Capacity
LOG Destination= 18432 reports
Automatic download in TR0, IP0 or IP1
IP0 destination= 250 reports
IP1 destination= 40 reports
SM0 destination= 20 reports
SM1 destination= 20 reports
Memory of the last 320 secs. running
Buffer for 8 incoming text messages
Buffer for 8 outgoing text messages
Access Protection
Password up to 8 characters
Protection of Data Sent via GPRS
Evolutionary digital encryption (64 bits) encrypted with 64 bits KEY (independent for IP0 and IP1)
Download
i-Button Reader
- Driver ID reader/enabler for TRAX devices
- High resistance to rough handling
- Extended temperature range: -40°C to 85°C
- Electromagnetic discharge protection
- 64 bit inviolable unique code
Temperature Sensor
- Temperature sensor for cold storage
- Temperature range: -55° C to 125 °C
- Precision of: -10° C to 85° C ± 0.5 °C
- Multiple alarm configuration
- Factory calibration
- Surgical stainless steel sheath
- Extended temperature range silicone wire
